Bars
Important information regarding bar material products
For certain pieces, up to 80-100 mm of the indicated length may not be usable due to an unchromed surface.
The shipping fee displayed in the Cart and Checkout is for informational purposes only.
For bar materials, the actual shipping cost may differ from the initially calculated amount due to the specific volume or weight of the package.
When ordering non-full-length bars, a cutting fee is added to the final amount based on the following pricing:
| Up to 60 mm shaft diameter | 750 HUF / cut |
|---|---|
| Above 60 mm shaft diameter | 1250 HUF / cut |
| Hardened materials | 1500 HUF / cut |
| Stainless materials | 1500 HUF / cut |
| Steel pipe | 1000 HUF / cut |
Size charts and descriptions of chromed rods
20MnV6 Chromed Round Steel Description
Polished and hard-chromed round steel.
| Material quality | 20MnV6 - 1.5217 |
|---|---|
| Tolerance | f7 / f8 |
| Chrome layer thickness | <⌀20: min 15 µm ≥⌀20: min 20 µm |
| Hardness | 63 - 68 HRC |
| Roughness | Ra max. 0.25 µm |
| Straightness | 0.3 mm / 1000 mm |
Mechanical Properties
| Tensile strength (Rm) | > 500 |
|---|---|
| Yield strength (Rp 0.2) | > 380 |
| Elongation (A%) | > 16 |
Average Chemical Composition
| C | Max 0.24% |
|---|---|
| Mn | Max 1.60% |
| P | Max 0.025% |
| Si | Max 0.45% |
| V | Max 0.15% |
| S | Max 0.030% |
20MnV6 Chromed Round Steel Size Chart
Click on the article number to view the selected product's price and stock availability.
| Article Number | ⌀ (mm) | kg / m | Tolerance |
|---|---|---|---|
| CKRM010000 | 10.00 | 0.62 | f8 |
| CKRM012000 | 12.00 | 0.89 | f8 |
| CKRM014000 | 14.00 | 1.21 | f8 |
| CKRM015000 | 15.00 | 1.39 | f8 |
| CKRM016000 | 16.00 | 1.58 | f8 |
If you have not purchased bar material from us before, please complete the Reverse Tax Declaration form and send it back to us via email.
Please return the document to webaruhaz@ogszhidraulika.hu.
Download
Kolbenstange verchr. 38,1mm (1,5")f7 20MnV6
Article number: CKRM038100
0.0718 € + VAT
1239 mm in stock
Kolbenstange verchr. 44,45 mm (1,75")f7 20MnV6
Article number: CKRM044450
0.0990 € + VAT
9189 mm in stock
Kolbenstange verchr. 50,8mm (2") f7 20MnV6
Article number: CKRM050800
0.1361 € + VAT
1539 mm in stock
Kolbenstange verchr. 57,15mm (2,25")f7 20MnV6
Article number: CKRM057150
0.1485 € + VAT
8520 mm in stock
Kolbenstange verchr. 63,5mm (2,5") f7 20MnV6
Article number: CKRM063500
0.1856 € + VAT
9420 mm in stock
Kolbenstange verchr. 76,2mm (3") f7 20MnV6
Article number: CKRM076200
0.2351 € + VAT
4980 mm in stock
Kolbenstange verchr. 82,55mm (3,25") f7 20MnV6
Article number: CKRM082550
0.2227 € + VAT
3220 mm in stock
Kolbenstange verchr. 88,9mm (3,5") f7 20MnV6
Article number: CKRM088900
0.2227 € + VAT
1829 mm in stock
Kolbenstange verchr. 101,6mm (4") f7 20MnV6
Article number: CKRM101600
0.3341 € + VAT
6370 mm in stock
Kolbenstange verchr. 114,3,mm (4,5")f7 20MnV6
Article number: CKRM114300
0.4826 € + VAT
5950 mm in stock
Kolbenstange verchr. 15mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE01500R
0.0619 € + VAT
3740 mm in stock
Kolbenstange verchr. 16mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE01600R
0.0309 € + VAT
Available to order
Kolbenstange verchr. 18mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE01800R
0.0433 € + VAT
2139 mm in stock
Kolbenstange verchr. 20mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE02000R
0.0371 € + VAT
16888 mm in stock
Kolbenstange verchr. 22mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE02200R
0.0433 € + VAT
12080 mm in stock
Kolbenstange verchr. 25mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE02500R
0.0495 € + VAT
15170 mm in stock
Kolbenstange verchr. 28mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE02800R
0.0495 € + VAT
6619 mm in stock
Kolbenstange verchr. 30mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE03000R
0.0557 € + VAT
11051 mm in stock
Kolbenstange verchr. 31,75mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE03175R
0.1237 € + VAT
6719 mm in stock
Kolbenstange verchr. 32mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE03200R
0.0619 € + VAT
14145 mm in stock
Kolbenstange verchr. 35mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE03500R
0.0681 € + VAT
12309 mm in stock
Kolbenstange verchr. 36mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE03600R
0.0742 € + VAT
4839 mm in stock
Kolbenstange verchr. 38mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE03800R
0.0990 € + VAT
10889 mm in stock
Kolbenstange verchr. 38,1mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE03810R
0.0990 € + VAT
7895 mm in stock
Kolbenstange verchr. 40mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE04000R
0.0990 € + VAT
25981 mm in stock
Kolbenstange verchr. 42mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE04200R
0.1485 € + VAT
11500 mm in stock
Kolbenstange verchr. 44,45 mm (1,75")f7 42CrMo4 induktiv gehärtet
Article number: CKRE04445R
0.1609 € + VAT
5410 mm in stock
Kolbenstange verchr. 45mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE04500R
0.1114 € + VAT
34005 mm in stock
Kolbenstange verchr. 50mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE05000R
0.1361 € + VAT
8509 mm in stock
Kolbenstange verchr. 50,8 (2")mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE05080R
0.1980 € + VAT
10550 mm in stock
Kolbenstange verchr. 55mm f7 42CrMo4 induktivgehärtet
Article number: CKRE05500R
0.1485 € + VAT
4050 mm in stock
Kolbenstange verchr. 56mm f7 42CrMo4 induktivgehärtet
Article number: CKRE05600R
0.1609 € + VAT
7529 mm in stock
Kolbenstange verchr. 57,15 mm (2,25") f7 42CrMo4 induktiv gehärtet
Article number: CKRE05715R
0.1980 € + VAT
7090 mm in stock
Kolbenstange verchr. 60mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE06000R
0.1856 € + VAT
18643 mm in stock
Kolbenstange verchr. 63mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE06300R
0.2104 € + VAT
9129 mm in stock
Kolbenstange verchr. 63,5mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE06350R
0.2475 € + VAT
11770 mm in stock
Kolbenstange verchr. 65mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE06500R
0.2475 € + VAT
15808 mm in stock
Kolbenstange verchr. 70mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE07000R
0.2475 € + VAT
17992 mm in stock
Kolbenstange verchr. 75mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE07500R
0.2599 € + VAT
21993 mm in stock
Kolbenstange verchr. 80mm f7 42CrMo4 induktiv gehärtet
Article number: CKRE08000R
0.3094 € + VAT
32634 mm in stock
Kolbenstange verchr. 82,55mm f7 (3,25")42CrMo4 induktiv gehärtet
Article number: CKRE08255R
0.3712 € + VAT
2009 mm in stock
