Tube Coupling - (SV-UNF) - ORFS - 11/16
12.5226 € + VAT
Qty:pcs
Add to Cart

Tube Coupling - (SV-UNF) - ORFS - 11/16"-16 UNF

12.5226 € + VAT
Qty:pcs
Add to Cart
Material Steel
Connection 1 UNF male thread
Connection 2 UNF male thread
Connection G1 - G2 (mm) 11/16" -16 UN
Connector sub-type UNF menet - ORFS kivitel (SV-ORFS)
Connector type Falazatátvezető - SV
Surface Galvanic coating
S1 (mm) 27
SW (mm) 27
Standard ISO 8434-2
Structural form Bulkhead Fitting - SV
Sealing 1 Flat sealing O-ring
Sealing 2 Flat sealing O-ring
Model: HQCOSV0600
Availability: 4 pcs in stock
Manufacturer: Nem besorolt
