Tube Coupling (EL-BSP) - (H-K-K) - G1/2
15.0226 € + VAT
Qty:pcs
Add to Cart

Tube Coupling (EL-BSP) - (H-K-K) - G1/2"

15.0226 € + VAT
Qty:pcs
Add to Cart
Material Steel
Connection 1 BSPP male thread
Connection 2 BSPP female swivel nut
Connection 3 BSPP male thread
Connection F1 (inch) 1/2''
Connection F2 (mm) 1/2''
Connector sub-type BSP hollander belső/külső menet (EL-BSP) (H-K-K)
Connector type L-idom rátét - EL
Surface Galvanic coating
H1 (mm) 22
H2 (mm) 27
L1 (mm) 36.5
L2 (mm) 39
Structural form L-fitting Insert - EL
Sealing 1 60° internal cone
Sealing 2 60° external cone
Sealing 3 60° internal cone
Operating pressure (bar) 315
Operating pressure (PSI) 4568
Manufacturer article number: TMG08FGG08B
Model: HQCCEL0800
Availability: 5 pcs in stock
Manufacturer: Nem besorolt
