Tube Coupling (EGE-BSP) - G1
11.2500 € + VAT
Qty:pcs
Add to Cart

Tube Coupling (EGE-BSP) - G1"

11.2500 € + VAT
Qty:pcs
Add to Cart
Material Steel
Connection 1 BSPP external thread
Connection 2 BSPP female swivel nut
Connection F1 (inch) 1''
Connection F2 (mm) 1''
Connector sub-type BSP menet (EGE-BSP)
Connector type Egyenes rátét becsavarható - EGE
Surface Galvanic coating
H1 (mm) 38
H (mm) 41
L1 (mm) 18
L (mm) 58.5
Structural form Straight Screw-in Insert - EGE
Sealing 1 60° internal cone, flat sealing
Sealing 2 60° external cone
Operating pressure (bar) 200
Operating pressure (PSI) 2900
Main category Fittings
SubCategory Swivel nut male stud coupling - EGE
Manufacturer Nincs
Manufacturer article number: AMFDG1616
Model: HQCCEG16000
Availability: 9 pcs in stock
Manufacturer: Nem besorolt
