Material	Steel
Connector sub-type	Metrikus menet - könnyű/nehéz kivitel (SKA-L/S)
Connector type	Hegeszthető csővég - SKA
Pipe size (mm)	8
d7 (mm)	5
Ø d1 (mm)	8
Surface	Galvanic coating
l2 (mm)	31.5
Design	L - S
l1 (mm)	31
Standard	DIN 2353/ISO 8434-1
Structural form	Weldable tube end - SKA
Sealing 1	24° external cone
Sealing 2	Welding filler material
Operating pressure (bar)	400
Manufacturer article number:	SANW06DKOL 1
Model:	HQCAK08LS0
Availability:	5 pcs in stock
Manufacturer:	Nem besorolt
