Material	Steel
Connector sub-type	Metrikus menet - nehéz kivitel (SKA-S)
Connector type	Hegeszthető csővég - SKA
Pipe size (mm)	16
d7 (mm)	12
Ø d1 (mm)	16
Surface	Galvanic coating
l2 (mm)	41
Design	S
l1 (mm)	39
Standard	DIN 2353/ISO 8434-1
Structural form	Weldable tube end - SKA
Sealing 1	24° external cone
Sealing 2	Welding filler material
Operating pressure (bar)	315
Manufacturer article number:	739983
Model:	HQCAK16L00
Availability:	8 pcs in stock
Manufacturer:	Nem besorolt
