Tube Coupling - WE 12-LR
6.0414 € + VAT
Qty:pcs
Add to Cart

Tube Coupling - WE 12-LR

6.0414 € + VAT
Qty:pcs
Add to Cart
Material Steel
Connection 1 BSPT male thread
Connection 2 Metric male thread
Connection G1 (mm) R 3/8" K
Connection G2 (mm) M18x1,5
Connector sub-type Metrikus/BSP menet - könnyű kivitel (WE-L/R)
Connector type Könyök becsavarható - WE
Ø d2 (mm) 12
Surface Galvanic coating
i (mm) 12
Design L
L4 (mm) 17
L5 (mm) 28
L7 (mm) 24
SW (mm) 17
Standard DIN 2353/ISO 8434-1, DIN 3852-1
Structural form Screw-in Elbow Fitting - WE
Extent Swivel nut, without cutting ring
Sealing 1 Thread-sealing
Sealing 2 24° internal cone
Operating pressure (bar) 315
Manufacturer article number: WRNW10HL
Model: HQCWE12LR060
Availability: 29 pcs in stock
Manufacturer: Nem besorolt
