Subtype	Power-regulated
Connections	1.1/16-12 UN-2B
Rotational speed at working pressure (min-max)	1000-1800
Direction of rotation	jobb
Mounting flange + screw mounting	82,55/106,4×2 (M10)
Mounting flange standard	ISO3019-1-82-2 - SAE A
Pressure Connection	1.1/16-12 UN-2B
Key [mm]	4,75×4,75×25,4
Regulation	nyomáskompenzálás - 20-210 bar
Displacement (cm³/rev)	10.5
Suction connection	1.1/16-12 UN-2B
Shaft [mm]	SAE AH - Ø19,05
Type	Egy körös
Seal	NBR
Maximum pressure	210 bar
Type	Single-circuit
Manufacturer article number:	02-341576
Model:	HPATPVQ1A2RSE1S
Availability:	1 pcs in stock
Manufacturer:	Eaton
